Multi-Purpose Flammability Cabinet
The Thermtech Multi-Purpose Flammability Test Cabinet (Model MPE-FAA) is designed to determine the resistance of materials to flame
when tested in accordance to Federal Aviation Regulation (FAR) 25.853 and 25.855. The Thermtech Muli-Purpose enclosure
is specifically designed in accordance to the FAA standards as outlined within the Aircraft Materials Fire Test Handbook.
Designed for Aerospace Testing
Model: MP-FAA
Download our Aerospace Brochure for more detailed information on our Flammability Test Cabinets.
Download Brochure
Take a look at additional detailed photos of our Vertical Flammability Test Cabinet.
Additional Photos
Multi-Purpose Flammability Chamber (Model: MP-FAA)
Specifications
The following standard features are provided on our multi-purpose test cabinet. Our MP-FAA flammability cabinet meets the Federal Aviation Regulations (FAR).
FAR Part 25 Appendix F Part 1
Airbus AITM 2.0002
Boeing BSS 7230
Test Cabinet is designed in accordance to the FAA issued Aircraft Materials Fire Test Handbook
Standard Features
a.) Vertical Bunsen Burner Test for Cabin & Cargo Compartment Materials
b.) 45-Degree Bunsen Burner Test for Cargo Compartment Liners and Waste Stowage Compartment Material
c.) Horizontal Bunsen Burner Test for Cabin and Cargo Compartment
d.) 60 Degree Bunsen Burner Test for Electric Wire
1.) Enclosure includes all necessary specimen holders to conduct following tests:
2.) Push / pull easy slide trolley allows operator to position Bunsen Burner under specimen
3.) Stainless steel enclosure construction
4.) Tempered observation glass
5.) 1/4" NPT gas connection with shut off valve
after enclosure door is closed and ready for the test to begin.
